Description
STANDARD FEATURES
Coupler Style: A-Frame
Ball Size: 2″
Safety Chains: 1/4″ with Safety Latch
Jack: 2K A-Frame
Plug: 4-Way
Tongue: 3″ Tubing
Main Frame: 2″ x 2″ x 1/8″ Angle
X-Members: 2″ x 2″ x 1/8″ Angle
Axles: 3,500 lb
GVWR: 2,990 lb
Brakes: Optional
Side Panel: Smooth
Ramp: 1.5″ x 1.5″ Tubing
Fender Type: Smooth
Tire Size: ST205/75R15C
Tire Type: Steel Belted Radials (Nitrogen Filled)
Tire PSI: 50+
Tire Weight Rating: 1,820 lb
Lighting (Clearance): LED Bullet
Lighting (Stop): Sealed LED (10 Diode)
Decking: 2×6 Doug Fur (Premium)
Paint Type: Polyurethane
Paint Color: High Gloss Black
Warranty: 3-Year Structural (Limited)
Ball Size: 2″
Safety Chains: 1/4″ with Safety Latch
Jack: 2K A-Frame
Plug: 4-Way
Tongue: 3″ Tubing
Main Frame: 2″ x 2″ x 1/8″ Angle
X-Members: 2″ x 2″ x 1/8″ Angle
Axles: 3,500 lb
GVWR: 2,990 lb
Brakes: Optional
Side Panel: Smooth
Ramp: 1.5″ x 1.5″ Tubing
Fender Type: Smooth
Tire Size: ST205/75R15C
Tire Type: Steel Belted Radials (Nitrogen Filled)
Tire PSI: 50+
Tire Weight Rating: 1,820 lb
Lighting (Clearance): LED Bullet
Lighting (Stop): Sealed LED (10 Diode)
Decking: 2×6 Doug Fur (Premium)
Paint Type: Polyurethane
Paint Color: High Gloss Black
Warranty: 3-Year Structural (Limited)
AU508SA (MODEL) – SPECIFICATIONS
Tongue Length: 46 1/2″
Interior Length: 97″
Interior Width: 59 1/2″
Overall Width: 78″
Overall Length: 145″
Deck Height: 18 1/2″
GVWR: 2,990 lb
Curb Weight: 760 lb
Payload Capacity: 2,230 lb
