Description
DESCRIPTION
Coupler Style Adjustable (5 Position)
Coupler Style Adjustable (5 Position)
Tire Size ST 225/75R15D – ST 235/80R15E
Ball Size 2 5/16″
Ball Size 2 5/16″
Bolt Pattern 6 on 5.5 – 8 on 6.5
Saftey Chains 5/16″ w/Clevis Latch –
3/8″ w/Clevis Latch
Saftey Chains 5/16″ w/Clevis Latch –
3/8″ w/Clevis Latch
Tire Type Steel Belted Radials (Nitrogen Filled)
Jack 7K Drop Leg
Jack 7K Drop Leg
Tire PSI 65# – 80#
Plug 7 Way RV
Plug 7 Way RV
Tire Weight Rating 2,540# – 3,520#
Tongue 5 x 2 x .188 Tubing
Tongue 5 x 2 x .188 Tubing
Lighting (Clearance) LED Bullet
Main Frame 5 x 3 x .188 Tubing
Main Frame 5 x 3 x .188 Tubing
Lighting (Stop) LED “Gloss Light” (22 Diode)
X-members 3″ Channel (18″ on Center)
X-members 3″ Channel (18″ on Center)
Paint Type Polyurethane
Axles 5200#
Axles 5200#
Paint Color High Gloss Black or Charcoal Metallic
Brake Electric
Brake Electric
Warranty Lifetime Structural (Limited)
Brake Size 12″ x 2″
Brake Size 12″ x 2″
Ramps 7′ Ramps (Channel)
Side Wall 12ga (1 Piece)
Side Wall 12ga (1 Piece)
Chain Tray Standard
Floor 10ga (1 Piece)
Floor 10ga (1 Piece)
Spreader Gate Standard
D-Rings 4 – 5/8″
D-Rings 4 – 5/8″
Tarp Bracket Standard
Fender Type Diamond Plate
Fender Type Diamond Plate
