Description
STANDARD FEATURES
Coupler Style: A-Frame
Fender Type: Teardrop (Smooth)
Ball Size: 2 5/16″
Tire Size: ST 205/75R15C
Safety Chains: 5/16″ W/ Safety Latch
Bolt Pattern: 5 on 4.5
Jack: 2K A-Frame
Tire Type: Steel Belted Radials (Nitrogen Filled)
Plug: 7 Way RV
Tire PSI: 50#
Tongue: 5″ Tube (Full Wrap)
Tire Weight Rating: 1820#
Main Frame: 5″ Channel
Lighting (Clearance): LED Bullet
X-Members: 3″ Channel (18″ on Center)
Lighting (Stop): Sealed LED Gloss Light (22 Diode)
Axles: 3500#
Decking: 2×6 Doug Fir (Premium)
Brake: Electric
Paint Type: Polyurethane
Brake Size: 10″ x 2.25″
Paint Color: High Gloss Black or Charcoal Metallic
Ramps: 5′ Ramps (Channel)
Warranty: Lifetime Structural (Limited)
D-Rings: 4 – 1/2″
Fender Type: Teardrop (Smooth)
Ball Size: 2 5/16″
Tire Size: ST 205/75R15C
Safety Chains: 5/16″ W/ Safety Latch
Bolt Pattern: 5 on 4.5
Jack: 2K A-Frame
Tire Type: Steel Belted Radials (Nitrogen Filled)
Plug: 7 Way RV
Tire PSI: 50#
Tongue: 5″ Tube (Full Wrap)
Tire Weight Rating: 1820#
Main Frame: 5″ Channel
Lighting (Clearance): LED Bullet
X-Members: 3″ Channel (18″ on Center)
Lighting (Stop): Sealed LED Gloss Light (22 Diode)
Axles: 3500#
Decking: 2×6 Doug Fir (Premium)
Brake: Electric
Paint Type: Polyurethane
Brake Size: 10″ x 2.25″
Paint Color: High Gloss Black or Charcoal Metallic
Ramps: 5′ Ramps (Channel)
Warranty: Lifetime Structural (Limited)
D-Rings: 4 – 1/2″
SPECIFICATIONS
Tongue Length: 49″
Deck Length: 194″
Deck Width: 83″
Overall Width: 102″
Overall Length: 246 1/4″
Fender Height: 8 1/8″
Deck Height: 21″
GVWR: 7000#
Curb Weight: 1,873#
Payload Capacity: 5,127#
