Description
STANDARD FEATURES
- Coupler Style: Adjustable (5 Position)
- Fender Type: Teardrop (Diamond Plate)
- Ball Size: 2 5/16″
- Tire Size: ST 235/80R16E
- Safety Chains: 3/8″ W/ Clevis Latch
- Bolt Pattern: 8 on 6.5
- Jack: 7K Drop Leg
- Tire Type: Steel Belted Radials (Nitrogen Filled)
- Plug: 7 Way RV
- Tire PSI: 80#
- Tongue: 6″ Channel (Full Wrap)
- Tire Weight Rating: 2540#
- Main Frame: 6″ Channel
- Lighting (Clearance): LED Bullet
- X-Members: 3″ Channel (18″ on Center)
- Lighting (Stop): Sealed LED (24 Diode)
- Axles: 7000#
- Decking: 2×6 Doug Fir (Premium)
- Brake: Electric
- Paint Type: Polyurethane
- Brake Size: 12″ x 2″
- Paint Color: High Gloss Black or Charcoal Metallic
- Ramps: 5′ Ramps (Channel)
- Warranty: Lifetime Structural (Limited)
- D-Rings: 4 – 5/8″
SPECIFICATIONS
- Tongue Length: 49″
- Deck Length: 242″
- Deck Width: 83″
- Overall Width: 102″
- Overall Length: 294 1/4″
- Fender Height: 7 3/4″
- Deck Height: 22 1/2″
- GVWR: 14,000 lbs
- Curb Weight: 2,559 lbs
- Payload Capacity: 11,441 lbs
